 Q: How do I install the awning?
Two"U" shaped brackets are screwed to the top of your van.
Brackets are provided with the awning.
Here is a sample installation procedure:
1) Order awning (this one came with stainless steel mounting brackets, silver reflective material and extra fiberglass poles for wind).
2) Gary Miller, Personalized Vans & Trucks, using an air wrench to power drive the mounting screws into the bus. Ouch!
Q: Will I also need to drill it in?
A: Yes the brackets which are included have to be screwed into the roof of your van. The brackets come with double sided tape. This way you can place the awning on the roof, make sure it clears the top, and then when you have situated it properly you can then mark the holes, drill and screw. It is very easy. Tip: locate the brackets up where the pop-top rubber trim fits into the "U" of the bracket when the top is down.
3) Caulking the fittings
4) Installation finished! This is easily a DIY job. You need a center punch, 5/32 drill bit, Loctite Silicone.
Q: Does it come with installation instructions?
A: Yes, the instructions will explain everything for you to do the job just right. Everything from the size of the drill that you will need to how to mount the brackets. And setup is quick and easy and takes only one person.
A shady drive way. Cocktail time!
One last trick, - the center rod goes in last and comes out first. Here
is another photo of the "U" shaped bracket installed
on a Vanagon:
Q:
Is the awning easily removable for those times it not going to be needed?
A: Yes you can remove the awning at any time. The brackets do
need to stay on your van. And the Awning is small enough so that it
looks good on your van. It is also light enough (less
than 15 pounds) so it will not affect your mileage.
Q:
Can you help me install it?
A: Yes, our installers in California can install one for you.
We ship the awning and they install it. Visit our installer's websites
(open in new window):
Volks
Cafe, Santa Cruz
Personalized
Vans and Trucks, San Jose
